| Quantity: | |
|---|---|
Scope of application:
Vertical horizontal combustion integrated testing machine, suitable for lighting equipment, electronic wires, low-voltage electrical appliances, household appliances, machine tools, electrical tools, electronic instruments, electrical instruments, electrical connectors and accessories and other electrical and electronic products and components of the research, production and quality inspection department, also suitable for insulation materials, engineering plastics or other solid combustible materials industry. Fire resistance test of wire and cable insulating coating materials, printed circuit board materials, IC insulators and other organic materials.
Product features:
1, the horizontal and vertical combustion test mainly refers to UL 94-2006, IEC 60695-11-4, IEC 60695-11-3, GB/T5169-2008 series and other standards using the specified size of Bunsen burner and specific gas sources (methane or propane), According to a certain flame height and a certain flame Angle, the test product in a horizontal or vertical state is burned several times, and the flammability and fire risk of the test product are assessed by the ignition, hot burning duration and burning length.
2. UL94 horizontal and vertical combustion tester is mainly used to grade the flammability of V-0, V-1, V-2, HB and 5V grade materials. Suitable for lighting equipment, electronic wires, low-voltage electrical appliances, household appliances, machine tools, electrical tools, electronic instruments, electrical instruments, electrical connectors and accessories and other electrical and electronic products and components of the research, production and quality inspection department, also suitable for insulation materials, engineering plastics or other solid combustible materials industry. Fire resistance test of wire and cable insulating coating materials, printed circuit board materials, IC insulators and other organic materials. During the test, the specimen was placed on the top of the fire, burned for 15 seconds, extinguished for 15 seconds, and checked the burnt condition of the specimen after re-review.
Product parameters：
| Burner: | with diameter of Φ9.5mm (12) ±0.3mm single gas mixed gas Bunsen burner |
| Test dip Angle: | 0°, 20°, 45° 65.90 Manual switch |
| Flame height: | 20mm ± 2mm to 180mm± 10mm adjustable |
| Flame time: | 0-999.9s±0.1s |
| Adjustable afterflame time: | 0-999.9s±0.1s, |
| Residual burning time: | 0-999.9s±0.1s |
| Counter: | 0-9999 |
| Combustion gas : | 98% methane gas or 98% propane gas (liquefied petroleum gas can be substituted in general), gas provided by customer |
| Flow pressure: | with flowmeter (gas) |
| Overall dimensions (L × W × H) : | 105 cm x65cm x 130cm |
| Test background: | black background |
| Position adjustment: | a. Sample clip bracket can be adjusted up and down, left and right, front and back, accurate alignment: |
| b. The combustion seat (blowtorch) can be adjusted before and after, the adjustment stroke is greater than 300 mm. | |
| Operation process: | a. The sample clip bracket is automatically raised and lowered electrically, which facilitates accurate alignment at any time during combustion and ensures more accurate test results: |
| b. Combustion seat (blowtorch) automatically moves forward and backward, accurate alignment, automatic timing, to ensure the application of flame and accurate timing: | |
| c. Automatic electromagnetic high voltage ignition, close. | |
| Test process: | Test program Manual/automatic control, independent ventilation, lighting |
| Studio volume | 0.5 cubic (other sizes can be customized) |
| Case material: | Baking paint |
| Control mode: | key |
| Power supply voltage: | 220VAC 50HZ |
