1. Φ8mm and Φ4mm dual apertures can be freely switched, making it easier to measure concave samples in a large plane;
2. Higher measurement stability and accuracy, ΔE*ab<0.03, double-caliber test data can pass the national metrology test certification;
3. Multiple color spaces, multiple color indices, wider applicability;
4. Dual positioning: light positioning, cross positioning;
5. Equipped with high-capacity rechargeable lithium-ion battery;
6. Built-in whiteboard parameters, and configure physical whiteboard at the same time, easy to operate;
7. New integrating sphere design, more stable measurement.
| Lighting method | 8°/d (8° lighting diffuse reflectance reception); conforms to the standard CIE No.15, GB/T 3978. |
| Lighting source | LED light source |
| Sensor | Silicon Photodiode |
| Measuring diameter | Φ8/Φ4mm |
| Color space | CIE LAB, XYZ, LCh, CIE RGB, CIE LUV |
| Color difference formula | ΔE*ab,ΔE(h),ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00 |
| Other chromaticity indicators | yellowness, whiteness, color fastness, color fastness |
| Observer angle | CIE 10° standard observer |
| Observation light source | D65, A, D50 |
| Display | chromaticity value, color difference value/graph, pass/fail result, color bias |
| Measurement time | 1.5s |
| Repeatability | within Φ8mm/ΔE*ab 0.06 (after the instrument is warmed up and calibrated, the average value of the white board is measured 30 times at an interval of 5s) |
| Inter-stage difference | within ΔE*ab 0.4 (the average value of 12 BCRA series II swatches) |
| Size | 205X70X100mm |
| Weight | about 400g (including battery) |
| Battery Level | Rechargeable Li-Ion Battery 3.7V @ 3200mAh |
| Lighting light source life | 5 years, more than 1.6 million measurements |
| Display | TFT true color 2.8inch@ (16:9) |
| Interface | USB |
| Positioning method | spot positioning, camera positioning |
| Storage data | 100 standard samples, 20000 samples |
| Operating temperature range | 0~40°C (32~104°F) |
| Storage temperature range | -20~50°C (-4~122°F) |
| PC software | CQCS3 high-end quality management software |
| Standard accessories | power adapter, manual, quality management software (download from official website), data cable, whiteboard box, Φ8 measuring diameter, Φ4 measuring diameter, lithium battery |
| Optional accessories | micro-printer, powder test box, multi-function test component, Φ8 lengthened measuring caliber |
