| Quantity: | |
|---|---|
1. Strength test: the maximum pressure resistance and displacement of the box can be measured;
2. Fixed value test: the overall performance of the box can be detected according to the set pressure or displacement;
3. Stacking test: according to national or international standards, stacking tests with different time, different conditions and different force values can be carried out.
4. Automatic calibration: the system can automatically realize the calibration of the indication accuracy;
5. Automatic shift: automatically switch to the appropriate range according to the size of the test force to ensure the accuracy of the measurement data;
6. Automatic display: During the whole test process, the test force, displacement and deformation are displayed in real time;
7. Automatic control: After the test parameters are input, the test process can be completed automatically;
8. Test judgment: After meeting the test requirements, the moving beam will automatically stop moving;
9. Limit protection: with mechanical and program-controlled two-level limit protection;
10. Test report: simple data report can be printed;
11. Manual calculation: part of the data needs to be manually recorded test results and process data;
Product parameters:
| Test force (KN) | 300/10 |
| Test force accuracy | better than ±1% |
| Test force classification | no classification in the whole process |
| Constant pressure accuracy | ±1% |
| Test force measurement range (KN) | 1% of full scale |
| Loading speed (KN/S) | 2.4KN/S main 200N/s 5ON/S main 10N/s |
| Relative error of force control rate | ±1% |
| Upper platen size (mm) | D140 |
| Lower platen size (mm) | D140 |
| Upper and lower platen distance (mm) | 250 |
| Effective stroke (mm) | 300 |
| Power supply (kw) | 1.5 |
| Power supply | conventional voltage 220V, can also be configured according to the standard voltage of the ground |
| Machine form | double column (distance between columns 300mm) |
| Dimensions (mm) | 950×650×1405 |
| Machine weight (kg) | 350 |
| Attachment | A set of anti-compression aids 40*40mm |
