| Quantity: | |
|---|---|
1, 1, 2, 3, 4, 5 load (angle) spring constant automatic test, the measurement of free angle can be easily completed.
2. The automatic origin correction function completes the calculation and compensation of the rigid structure of the load cell and the material of the machine, ensuring high-precision measurement.
3. The touch screen man-machine dialogue type test condition setting input is more convenient and fast.
4. In order to facilitate the calculation and input of tolerance, the system will automatically calculate the upper and lower limit values after inputting the tolerance percentage value.
5. There are as many as a dozen test types, which can not only meet the production measurement, but also meet the spring engineering design requirements.
6. The test load units are N.m, Kg.cm, Lb.in.
7. For the convenience of operation, the measurement range can be freely converted into 5 test ranges.
8. Through the turntable, the position of the load test plug gauge and the rotary plug gauge can be automatically corrected to obtain the accurate zero point position.
9. The system is equipped with overload protection and emergency shutdown functions.
10. The system can automatically test by setting the number of repeated cycles through simple operations.
11. With data printing function.
12. Rotation displacement control button, with 10 degree, 1 degree, 0.1 degree slow-moving rotation level, can control the angle accurately.
Product parameters:
| Upper Torque (N.m) | 1, 3, 5, 10, 20 |
| Lower limit torque display value | 0.0001/0.001 |
| Unit | N.m, Kg.cm, Lb.in |
| Test speed | 1-1800deg/min |
| Test angle | 7200deg |
| Power supply | AC 200V (110AC) |
| Dimensions (mm) | 697*450*623 |
| Weight (kg) | 120 |
